800-10-006-40-002000

Headers, Male Pins Overview

The Mill-Max 800-10-006-40-002000 is a surface mount header connector featuring six positions with a 0.100-inch (2.54mm) pitch. Designed for board-to-board applications, this component utilizes straight termination methods suitable for automated assembly processes. The unit belongs to the standard pin header product line and is packaged in bulk quantities for efficient manufacturing integration.

Headers, Male Pins Feature Summary

• Surface mount configuration for direct PCB attachment
• Six-position layout with standardized spacing
• Straight termination style for reliable electrical connection

Headers, Male Pins Applications

• Board-to-board interconnect systems
• General electronic circuit assembly
• Standard header applications requiring surface mount technology

Headers, Male Pins Procurement Notes

Verify the specific surface mount package dimensions and terminal finish requirements against your PCB design guidelines before ordering. Confirm that the six-position configuration aligns with your circuit schematic. Ensure compatibility with your reflow soldering profile to maintain connection integrity during assembly.

Headers, Male Pins Selection Notes

Select this component when a low-profile surface mount header is required for six connections. The 2.54mm pitch ensures compatibility with standard through-hole mating connectors. Consider the straight termination style for straightforward board alignment and secure mounting without additional mechanical fasteners.

Headers, Male Pins Part Context

This part belongs to Mill-Max's standard pin header series, which provides high-reliability interconnect solutions. The manufacturer specializes in precision-machined components for diverse electronic applications. This specific model represents a common configuration within their extensive catalog of surface mount headers.

Headers, Male Pins Replacement Considerations

Check for identical six-position surface mount headers with matching 2.54mm pitch from other manufacturers. Verify that alternative parts support the same straight termination style and surface mount footprint to ensure mechanical and electrical compatibility.
