800-10-011-10-001101

Headers, Male Pins Overview

The Preci-Dip 800-10-011-10-001101 is a single-row male header connector featuring 11 positions with a 2.54 mm (0.100 inch) mating pitch. Designed for through-hole termination, this component utilizes brass contacts with gold plating to ensure reliable signal transmission. It operates within a voltage rating of 150 VDC and supports a current capacity of 3A across an operating temperature range of -55°C to 125°C. The housing is constructed from black glass-reinforced PCT polyester, meeting UL94 V-0 flammability standards. This vertical board-to-board connector provides a secure mechanical interface for electronic assemblies requiring robust interconnectivity.

Headers, Male Pins Feature Summary

• Features gold-plated brass contacts for enhanced conductivity and corrosion resistance
• Utilizes glass-reinforced PCT polyester insulation for structural stability and flame retardancy
• Supports vertical through-hole mounting for standard PCB integration

Headers, Male Pins Applications

• General-purpose electronic circuit interconnections
• Industrial control system board-to-board linking
• Consumer electronics internal wiring harnesses

Headers, Male Pins Procurement Notes

Verify the specific contact plating thickness and material composition against the official manufacturer datasheet prior to implementation. Confirm that the thermal profile during soldering remains within the specified -55°C to 125°C operational limits to prevent insulation degradation. Ensure compatibility with mating female connectors regarding pin count and pitch alignment to maintain electrical continuity.

Headers, Male Pins Selection Notes

Select this component when a vertical, single-row configuration with 11 pins is required for through-hole assembly. The 2.54 mm pitch aligns with standard industry spacing, while the gold plating offers superior performance over tin variants in high-cycle or corrosive environments. Consider the 3A current rating and 150V voltage limit to ensure compliance with the target circuit's power requirements and safety margins.

Headers, Male Pins Part Context

This part belongs to the Preci-Dip 800 series, which specializes in IC pin connectors available as right-angle wire-wrap headers or straight surface-mount sockets. The series is characterized by its 0.74 mm diameter pins and standardized 2.54 mm spacing. While other variants in the family may utilize tin plating or different orientations, this specific model emphasizes gold-plated contacts for improved durability in demanding applications.

Headers, Male Pins Replacement Considerations

• 800-10-011-10-001101

Headers, Male Pins FAQ

What is the flammability rating of the insulator?

The glass-reinforced PCT polyester insulation meets the UL94 V-0 flammability rating.

Does this connector support surface mount installation?

No, this specific model is designed exclusively for through-hole termination.
