800-10-041-30-480101

$5.53

Description：CONN HEADER SMD 41POS 2.54MM
Series：800
Mfr：Preci-Dip
Package：Bulk

SKU:3181c8941a5a Category: Headers, Male Pins Brand: Preci-Dip

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

800-10-041-30-480101 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Preci-Dip. Its product description is CONN HEADER SMD 41POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 800-10-041-30-480101

Description：CONN HEADER SMD 41POS 2.54MM
Series：800
Mfr：Preci-Dip
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：41
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.141" (3.60mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.110" (2.79mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：10.0µin (0.25µm)
Contact Finish - Post：Gold
Contact Material：Brass
Insulation Material：Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：150VDC

Headers, Male Pins datasheet and documents for 800-10-041-30-480101

800-10-041-30-480101

Headers, Male Pins Overview

The Preci-Dip 800-10-041-30-480101 is a surface mount header connector from the 800 series. It features 41 positions with a 2.54 mm (0.100 inch) pitch and one row. The contacts are male pins made of brass, plated with gold on both mating and tail surfaces to a thickness of 10.0 µin (0.25 µm). Rated for 3A current and 150V DC, it utilizes PCT polyester insulation reinforced with glass fiber. Operating temperature ranges from -55°C to 125°C, with UL94 V-0 flammability rating.

Headers, Male Pins Feature Summary

Surface mount installation with push-pull locking mechanism
Gold-plated brass contacts for reliable conductivity
High-density 41-position single-row configuration

Headers, Male Pins Applications

Board-to-board interconnections
General electronic circuit assembly
Industrial control systems

Headers, Male Pins Procurement Notes

Verify the manufacturer part number 800-10-041-30-480101 against official Preci-Dip documentation to confirm specifications. Ensure compatibility with surface mount assembly processes. Check for RoHS compliance status if required by project regulations. Confirm that the gold plating thickness meets application requirements.

Headers, Male Pins Selection Notes

Select this component when a high-pin-count surface mount header is required. The 2.54 mm pitch suits standard PCB layouts. Gold plating offers superior corrosion resistance compared to tin. Verify that the 150V DC rating aligns with system voltage constraints. Consider the 41-position count for space limitations.

Headers, Male Pins Part Context

This connector belongs to the Preci-Dip 800 series, designed for surface mount applications. It provides a robust connection solution for dense circuit board arrangements. The series is known for its reliability in various electronic environments. The specific model offers a balance of pin count and form factor.
