800-80-019-20-001101

Headers, Male Pins Overview

Preci-Dip part number 800-80-019-20-001101 is a single-row male header connector from the 800 series. It features a 2.54 mm (0.100 inch) pitch with 19 positions. The connector utilizes brass contacts with tin plating and a glass-filled PCT insulation body rated UL94 V-0. Designed for through-hole right-angle mounting, it supports a maximum voltage of 150V DC and a current rating of 3A. The operating temperature range spans from -55°C to +125°C.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting configuration for board-to-board connections
• Tin-plated brass contacts ensuring reliable signal transmission
• Glass-filled PCT insulation housing providing structural stability

Headers, Male Pins Applications

• General electronic equipment interconnections
• Industrial control system circuit boards
• Consumer electronics internal wiring

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Preci-Dip documentation to confirm exact pin count, contact material, and termination style. Ensure compatibility with mating socket dimensions and PCB hole patterns before integration. Cross-reference the manufacturer datasheet for updated environmental compliance status and RoHS directives applicable to this specific batch.

Headers, Male Pins Selection Notes

Select this component when a right-angle through-hole header with a 2.54 mm pitch is required. Confirm that the 19-position layout matches the design footprint. Verify that the 3A current rating and 150V voltage limit meet the circuit requirements. Check that the operating temperature range aligns with the intended environment.

Headers, Male Pins Part Context

This connector belongs to the Preci-Dip 800 series, which offers various configurations for standard interconnect needs. The series provides options for different row counts, pitches, and mounting styles. This specific model represents a high-density single-row solution suitable for compact PCB layouts requiring robust mechanical retention.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 19-position, 2.54 mm pitch right-angle headers from manufacturers such as Samtec or Molex. Ensure the replacement maintains identical pin spacing, contact plating, and insulation material properties for direct interchangeability.
