800-80-035-10-001101

Headers, Male Pins Overview

The Preci-Dip 800-80-035-10-001101 is a single-row male header connector featuring 35 contacts with a 2.54 mm (0.1 inch) pitch. Designed for through-hole mounting, it utilizes brass terminals with tin plating and a fiberglass-reinforced polyester insulator rated UL94 V-0. The component supports a maximum current of 3A and a voltage of 150V DC, operating within a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Single-row male pin configuration for board-to-board or cable connections
• Through-hole termination with standard 2.54 mm spacing
• High-temperature resistant fiberglass-reinforced polyester housing

Headers, Male Pins Applications

• General electronic equipment interconnections
• Industrial control system circuit boards
• Consumer appliance internal wiring

Headers, Male Pins Procurement Notes

Verify the specific suffix code against official Preci-Dip documentation to confirm terminal orientation and plating specifications. Ensure the selected variant matches the required PCB hole dimensions and mating connector compatibility. Cross-reference the manufacturer part number with authorized distributors to confirm current production status and availability.

Headers, Male Pins Selection Notes

Select this component when a high-density single-row connection is required for standard PCB layouts. The 2.54 mm pitch ensures compatibility with common ribbon cables and mating headers. Consider the 3A current rating and 150V voltage limit to ensure safe operation within the target circuit environment without exceeding thermal or electrical constraints.

Headers, Male Pins Part Context

This part belongs to the Preci-Dip 800 series, which offers various contact counts and mounting styles. It serves as a standardized rectangular connector solution for mass-produced electronics. The series provides consistent mechanical and electrical performance across different pin configurations, facilitating modular design approaches in hardware engineering projects.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 35-position, 2.54mm pitch male headers from manufacturers such as Samtec or Molex. Verify that alternative parts match the exact row count, terminal plating, and insulator material properties before integration.
