801-83-010-40-001191

$1.71

Description：CONN SOCKET 10P 0.1 GOLD SMD R/A
Series：801
Mfr：Preci-Dip
Package：Bulk

SKU:fd19fa0d7932 Category: Headers, Receptacles, Female Sockets Brand: Preci-Dip

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

801-83-010-40-001191 is listed in the Headers, Receptacles, Female Sockets range at ChipApex. The manufacturer field lists Preci-Dip. Its product description is CONN SOCKET 10P 0.1 GOLD SMD R/A. Review the specifications below when checking this part for your BOM.

Headers, Receptacles, Female Sockets specifications for 801-83-010-40-001191

Description：CONN SOCKET 10P 0.1 GOLD SMD R/A
Series：801
Mfr：Preci-Dip
Package：Bulk
Connector Type：Socket
Contact Type：Female Socket
Style：Board to Board
Number of Positions：10
Number of Positions Loaded：All
Pitch - Mating：0.100" (2.54mm)
Number of Rows：1
Row Spacing - Mating：-
Mounting Type：Surface Mount, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：29.5µin (0.75µm)
Insulation Color：Black
Insulation Height：0.100" (2.54mm)
Contact Length - Post：-
Operating Temperature：-55°C ~ 125°C
Material Flammability Rating：UL94 V-0
Contact Finish - Post：Tin
Mated Stacking Heights：-
Ingress Protection：-
Features：Pick and Place
Current Rating (Amps)：3A
Voltage Rating：-

Headers, Receptacles, Female Sockets datasheet and documents for 801-83-010-40-001191

801-83-010-40-001191

Headers, Receptacles, Female Sockets Overview

Preci-Dip part number 801-83-010-40-001191 is a socket connector from the 801 series. It features 10 positions with a 2.54 mm (0.100 inch) pitch. The connector utilizes surface mount technology in a right-angle configuration. Contact materials consist of beryllium copper, with gold plating on the mating surfaces and tin plating on the tails. The housing is constructed from black glass-reinforced PCT polyester, rated UL94 V-0. Electrical ratings include 3A current capacity and 150V DC voltage. Operating temperature ranges from -55°C to +125°C.

Headers, Receptacles, Female Sockets Feature Summary

Right-angle surface mount design for board-to-board interconnection
Gold-plated contacts ensure reliable signal transmission
Glass-reinforced PCT insulation provides thermal stability

Headers, Receptacles, Female Sockets Applications

Board-to-board electronic interconnections
Surface mount assembly for compact circuitry
Industrial control system interfaces

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific ordering suffix against official Preci-Dip documentation to confirm contact plating and packaging details. Ensure compatibility with automated pick-and-place equipment specifications. Confirm that the right-angle orientation matches the target PCB layout requirements before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a right-angle female socket interface is required for dense surface mount applications. The 2.54 mm pitch accommodates standard header counterparts. Gold plating is suitable for low-signal applications requiring corrosion resistance. Verify that the 3A rating meets the circuit's electrical load requirements.

Headers, Receptacles, Female Sockets Part Context

This connector belongs to the Preci-Dip 801 series, which specializes in surface mount sockets. The series offers various pin counts and orientations to support diverse PCB integration needs. The 801 series components are designed for high-density mounting environments where space efficiency and reliable electrical connections are critical for performance.
