Headers, Receptacles, Female Sockets Overview

The Preci-Dip 801-83-031-10-268101 is a 31-position socket connector designed for through-hole mounting. It features a 0.100-inch (2.54mm) pitch and utilizes gold-plated contacts to ensure reliable signal transmission. The housing is constructed from black polyester, providing structural integrity and compliance with UL 94 V-0 flammability standards. Rated for 3A current and 150VDC, it operates within a temperature range of -55°C to +125°C.

Headers, Receptacles, Female Sockets Feature Summary

• Single-row socket configuration with gold-plated copper alloy contacts
• Through-hole termination method for secure PCB attachment
• Black polyester housing material ensuring UL 94 V-0 flame retardancy

Headers, Receptacles, Female Sockets Applications

• General-purpose electronic interconnects
• Industrial control systems
• Consumer electronics assemblies

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific contact plating thickness and exact housing material grade against the manufacturer's official datasheet before procurement. Confirm that the single-row through-hole form factor aligns with the target PCB layout requirements. Ensure compatibility with mating header connectors in terms of pitch and contact geometry to prevent mechanical or electrical mismatch during assembly.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, single-row socket is required for board-to-board connections. The gold plating offers superior corrosion resistance compared to tin alternatives. Verify that the 3A current rating and 150VDC voltage limit meet the circuit's operational demands. Consider the thermal stability provided by the polyester insulation for environments experiencing significant temperature fluctuations.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the 801 series of straight socket connectors from Preci-Dip. The series is characterized by its very low profile design, making it suitable for space-constrained applications. The model number indicates a 31-contact variant with standard 2.54mm spacing, fitting into the broader portfolio of precision interconnect solutions offered by the manufacturer.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes include other 31-position, 2.54mm pitch single-row sockets from Preci-Dip, such as the 801-83-030-10-268101 or 801-83-032-10-268101, which share identical mechanical dimensions and electrical ratings. Cross-brand replacements must match the pin count, pitch, and mounting style precisely.
