801-83-034-65-410101

Headers, Receptacles, Female Sockets Overview

The Preci-Dip 801-83-034-65-410101 is a 34-position socket connector designed for press-fit termination. It features a 0.100 inch (2.54mm) pitch and female socket contacts. The housing is black polyester with UL94 V-0 flammability rating. Contacts are copper alloy, gold-plated at the mating interface and tin-plated on the post. It operates within -55°C to +125°C and supports 3A current.

Headers, Receptacles, Female Sockets Feature Summary

• Press-fit termination method for reliable board attachment
• Gold-plated mating contacts for corrosion resistance
• Black polyester insulation with UL94 V-0 rating

Headers, Receptacles, Female Sockets Applications

• Board-to-board interconnects requiring press-fit assembly
• High-reliability electronic systems
• Industrial control modules

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific part number suffix against official Preci-Dip documentation to confirm press-fit compatibility and contact finish specifications. Ensure the procurement matches the exact series designation to avoid functional mismatches in termination style or material composition.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when press-fit technology is required for high-density connections. Consider the 34-position count and 2.54mm pitch constraints. Verify that the operating temperature range and current rating meet the system requirements before integration.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Preci-Dip 801 series of rectangular connectors. It is specifically engineered for applications demanding robust mechanical retention through press-fit installation rather than traditional soldering methods.

Headers, Receptacles, Female Sockets Replacement Considerations

Consult official cross-reference lists for direct substitutes. Ensure replacement parts maintain identical press-fit termination and 0.100 inch pitch specifications.
