801-83-040-10-173101

Headers, Receptacles, Female Sockets Overview

The Preci-Dip 801-83-040-10-173101 is a 40-position socket connector from the PRECI-DIP series, designed for through-hole PCB mounting. It features a 0.100" (2.54mm) pitch and utilizes gold-plated contacts made of copper alloy. The connector supports a rated current of 3A and a voltage of 150VDC, operating within a temperature range of -55°C to +125°C. Constructed with UL94 V-0 rated insulation, it provides reliable signal transmission in board-to-board applications.

Headers, Receptacles, Female Sockets Feature Summary

• Gold-plated contact surfaces ensure reliable electrical conductivity and corrosion resistance
• Through-hole termination method secures stable mechanical connection to printed circuit boards
• High-temperature resistant insulation material maintains integrity across wide thermal ranges

Headers, Receptacles, Female Sockets Applications

• Data signal transmission systems
• Control circuit interconnections
• Power application interfaces

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific ordering suffix against official Preci-Dip documentation to confirm plating thickness and contact configuration. Ensure compatibility with mating header dimensions before procurement. Cross-reference the full part number with manufacturer catalogs to validate availability status and environmental compliance certifications such as RoHS.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a 40-position vertical socket with gold plating is required. Confirm that the 2.54mm pitch aligns with the target PCB layout. Evaluate the 3A current rating against system load requirements. Verify that the through-hole mounting style matches the assembly process capabilities.

Headers, Receptacles, Female Sockets Part Context

This model belongs to the PRECI-DIP family of precision connectors. Preci-Dip manufactures turned contacts compliant with ISO 9001 and MIL standards. The product line is recognized by Underwriters Laboratories for use in data, signal, control, and power applications, ensuring industry-standard safety and performance reliability.

Headers, Receptacles, Female Sockets Replacement Considerations

Consult official Preci-Dip cross-reference guides for verified substitutes. Generic equivalents may not match the precision turned contact specifications or UL listing requirements. Validate dimensional tolerances and plating specifications before considering alternative sources.
