801-83-057-20-442101

Headers, Receptacles, Female Sockets Overview

The Preci-Dip 801-83-057-20-442101 is a 29-position socket connector designed for board-to-board applications. It features a 0.200-inch (5.08mm) pitch and utilizes through-hole, right-angle mounting. The contacts are made of copper beryllium with gold plating on the mating interface and tin on the post. Rated for 3A at 150VDC, it operates within a temperature range of -55°C to 125°C. The housing is black PCT with glass fiber reinforcement, meeting UL94 V-0 flammability standards.

Headers, Receptacles, Female Sockets Feature Summary

• Push-pull locking mechanism ensures secure connection retention
• Gold-plated circular contacts provide reliable signal transmission
• Right-angle through-hole termination facilitates PCB layout flexibility

Headers, Receptacles, Female Sockets Applications

• Board-to-board interconnect systems
• Industrial control modules
• Communication equipment backplanes

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific part number against official Preci-Dip documentation to confirm pin count, contact finish, and mounting style. Ensure compatibility with the corresponding header series, such as the 800-80 series, for proper mating. Check RoHS compliance status and environmental certifications required for the target application before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a high-current, robust board-to-board connection is required with a wide operating temperature range. The push-pull feature is suitable for applications requiring frequent mating cycles or vibration resistance. Ensure the PCB design accommodates the right-angle profile and through-hole spacing constraints associated with the 5.08mm pitch.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Preci-Dip 801 series of rectangular connectors. It is specifically designed as a socket counterpart to the 800 series headers. The series emphasizes precision turned contacts and durable materials for demanding industrial environments. The model number encodes specific attributes regarding position, pitch, and termination type.

Headers, Receptacles, Female Sockets Replacement Considerations

Compatible substitute parts include the 801-87-057-20-442101 from Preci-Dip, which shares similar specifications. Verify mechanical dimensions and electrical ratings before substitution to ensure functional equivalence in the assembly.
