Headers, Receptacles, Female Sockets Overview

The Preci-Dip 801-87-032-10-012101 is a straight through-hole PCB header from the 801 series. It features 32 contacts with a 2.54 mm pitch and single row configuration. The connector utilizes brass and beryllium copper terminals, gold and tin plated, rated for 3A current and 150V DC voltage. Constructed with glass-filled polyester insulation, it operates within -55°C to 125°C.

Headers, Receptacles, Female Sockets Feature Summary

• Straight through-hole mounting design for reliable PCB integration
• Single row configuration with 32 contact positions
• Gold and tin terminal plating for corrosion resistance
• Glass-filled polyester housing for structural stability

Headers, Receptacles, Female Sockets Applications

• General purpose electronic interconnections
• Industrial control panel wiring
• Consumer electronics assembly
• Test equipment signal routing

Headers, Receptacles, Female Sockets Procurement Notes

Verify exact component specifications against official manufacturer datasheets prior to procurement. Confirm that the part number matches the required 32-position straight header configuration. Ensure compatibility with existing PCB footprint designs and mating connector requirements. Check for any specific environmental certifications or material compliance standards required by your application.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a high-density straight header is needed for through-hole assembly. The 2.54 mm pitch ensures standard spacing compatibility. Consider the 3A current rating and 150V voltage limit for circuit safety. Verify that the operating temperature range meets environmental conditions. Evaluate mechanical stability needs for the specific board layout.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Preci-Dip 801 series of headers and wire housings. The series offers various contact counts and configurations for diverse electronic applications. The 801 series is designed for general-purpose connectivity, providing reliable electrical connections in compact spaces. It supports both surface mount and through-hole technologies depending on the specific variant.

Headers, Receptacles, Female Sockets Replacement Considerations

Compatible substitutes include other 32-position 2.54mm pitch straight headers from manufacturers like Molex, Samtec, or Amphenol. Ensure identical pin count, pitch, and mounting style. Verify matching current and voltage ratings. Check housing material and termination type compatibility.
