801-87-038-53-001101

Headers, Receptacles, Female Sockets Overview

The Preci-Dip 801-87-038-53-001101 is a single-row socket connector featuring 38 positions with a 2.54 mm (0.100 inch) pitch. It utilizes through-hole termination for PCB mounting and operates within a temperature range of -55°C to +125°C. The contacts are made from copper alloy with gold plating, rated for 3 A current and 150 V DC voltage. The housing is constructed from black glass-filled polyester meeting UL94 V-0 flammability standards.

Headers, Receptacles, Female Sockets Feature Summary

• Single-row socket configuration designed for board-to-board stacking applications
• Gold-plated copper alloy contacts ensure reliable signal transmission
• Through-hole termination provides secure mechanical connection to the PCB

Headers, Receptacles, Female Sockets Applications

• Board-to-board interconnections in electronic assemblies
• Stacked circuit board architectures requiring vertical mating
• General-purpose signal routing in industrial control systems

Headers, Receptacles, Female Sockets Procurement Notes

Verify that the specific ordering suffix matches the required contact plating and housing material specifications. Confirm that the pin count aligns exactly with the design layout. Ensure compatibility with the mating header series before finalizing procurement orders to prevent interface mismatches.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a single-row, right-angle or straight socket is required for dense PCB layouts. The 2.54 mm pitch offers standard spacing for general electronics. Consider the 3 A rating for power distribution needs and verify thermal limits against the operating environment.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Preci-Dip 801 series, which specializes in single-row socket connectors. The series supports various pin counts and termination styles, providing modular solutions for diverse electronic interconnection requirements across multiple industry sectors.

Headers, Receptacles, Female Sockets Replacement Considerations

Compatible mating headers include the 801-87-038-10-001101 series. Verify that substitute parts maintain identical 2.54 mm pitch and 38-position geometry to ensure proper mechanical fit and electrical continuity.
