801-87-044-10-004101

Headers, Receptacles, Female Sockets Overview

The Preci-Dip 801-87-044-10-004101 is a vertical header connector featuring 44 positions with a 2.54mm pitch. It utilizes square pins made of brass with tin plating for reliable contact. The housing is constructed from black polyamide (PA) reinforced with glass fiber, ensuring UL94 V-0 flammability rating. Rated for 3A current and 150VDC voltage, it supports a wide operating temperature range from -55°C to 125°C. Designed for through-hole mounting, this component offers robust mechanical stability for board-to-board interconnections in demanding electronic environments.

Headers, Receptacles, Female Sockets Feature Summary

• Vertical pin header configuration with square contact geometry
• Tin-plated brass contacts for corrosion resistance
• Glass-fiber reinforced polyamide insulation for thermal stability
• Through-hole termination for secure PCB attachment

Headers, Receptacles, Female Sockets Applications

• Industrial control system interconnects
• Commercial equipment signal routing
• General-purpose board-to-board connections

Headers, Receptacles, Female Sockets Procurement Notes

Verify the exact part number against official Preci-Dip documentation to confirm specifications. Ensure compatibility with mating sockets regarding pin shape and pitch. Check for RoHS3 compliance requirements specific to your project regulations. Confirm lead times and availability directly with authorized distributors as supply chains may vary. Validate that the selected connector meets all environmental and electrical ratings required for the final application.

Headers, Receptacles, Female Sockets Selection Notes

Select this connector when a vertical header with square pins is required for 2.54mm pitch applications. Consider the 3A current rating and 150VDC voltage limit for circuit design. Choose based on the need for through-hole mounting and high-temperature resilience up to 125°C. Evaluate the black polyamide housing for UL94 V-0 fire safety compliance. Ensure sufficient panel space for the 44-position layout.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Preci-Dip 801 series of headers and wire housings. It is designed for general electronic interconnection needs. The series offers various position counts and configurations. Preci-Dip manufactures these connectors to meet strict quality standards. The 801 series is widely used in industrial and commercial sectors for reliable signal transmission.

Headers, Receptacles, Female Sockets Replacement Considerations

No public confirmed substitute part numbers are available in the provided data.
