802-10-058-20-001101

Headers, Male Pins Overview

The Preci-Dip 802-10-058-20-001101 is a male header connector from the 802 series, designed for board-to-board applications. It features a 2-row configuration with 58 positions and a 2.54 mm (0.100 inch) pitch. The unit utilizes through-hole termination with right-angle mounting orientation. Electrical ratings include a current capacity of 3A and a voltage rating of 150V. The contacts are made of brass with tin plating, housed in a black insulator constructed from glass-filled polyethylene terephthalate (PET). The operating temperature range spans from -55°C to +125°C.

Headers, Male Pins Feature Summary

• Right-angle board-to-board interconnection capability
• Tin-plated brass contacts for reliable conductivity
• Glass-filled PET insulation for thermal stability

Headers, Male Pins Applications

• General electronic circuit board interconnections
• Industrial control system modules
• Consumer electronics assembly

Headers, Male Pins Procurement Notes

Verify the specific part number against official Preci-Dip documentation to confirm pin count, pitch, and termination style. Ensure compatibility with mating socket connectors regarding contact length and housing dimensions. Confirm that the tin plating specification meets the environmental and electrical requirements of the target application before finalizing procurement.

Headers, Male Pins Selection Notes

Select this component when a right-angle, double-row header with a 2.54 mm pitch is required for PCB assembly. Consider the 3A current rating and 150V voltage limit to ensure safe operation within the circuit design. Verify that the through-hole mounting method aligns with the manufacturing process and that the operating temperature range suits the intended environment.

Headers, Male Pins Part Context

This connector belongs to the Preci-Dip 802 series, which offers various row counts and position options. The series is characterized by its standard 2.54 mm spacing and robust construction suitable for general-purpose electronic connections. The specific model provides a high-density option with 58 positions across two rows.

Headers, Male Pins Replacement Considerations

Compatible substitutes must match the 2.54 mm pitch, 2-row configuration, 58-position count, and right-angle through-hole mounting. Ensure the replacement maintains equivalent electrical ratings and material specifications.
