8020.0608.H

8020.0608.H is listed in the Fuses range at ChipApex. The manufacturer field lists SCHURTER Inc.. Its product description is FUSE CERM 40A 250VAC 80VDC 3AB. Review the specifications below when checking this part for your BOM.

Fuses specifications for 8020.0608.H

• Description：FUSE CERM 40A 250VAC 80VDC 3AB
• Series：SUT-H 6.3x32
• Mfr：SCHURTER Inc.
• Package：Box
• Mounting Type：Requires Holder
• Fuse Type：Cartridge, Ceramic
• Current Rating (Amps)：40 A
• Voltage Rating - DC：80 V
• Response Time：Slow Blow
• Package / Case：3AB, 3AG, 1/4" x 1-1/4"
• Breaking Capacity @ Rated Voltage：500A
• Melting I²t：5876
• Approval Agency：CE, CSA, cURus, UL
• Operating Temperature：-40°C ~ 85°C
• Color：-
• Size / Dimension：0.250" Dia x 1.252" L (6.35mm x 31.80mm)
• Voltage Rating - AC：250 V

Fuses datasheet and documents for 8020.0608.H
