803-83-022-10-132101 is listed in the Headers, Receptacles, Female Sockets range at ChipApex. The manufacturer field lists Preci-Dip. Its product description is CONN SOCKET 22POS 0.1 GOLD PCB. Review the specifications below when checking this part for your BOM.
Headers, Receptacles, Female Sockets specifications for 803-83-022-10-132101
- Description：CONN SOCKET 22POS 0.1 GOLD PCB
- Series：803
- Mfr：Preci-Dip
- Package：Bulk
- Connector Type：Socket
- Contact Type：Female Socket
- Style：Board to Board
- Number of Positions：22
- Number of Positions Loaded：All
- Pitch - Mating：0.100" (2.54mm)
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：29.5µin (0.75µm)
- Insulation Color：Black
- Insulation Height：0.276" (7.00mm)
- Contact Length - Post：0.118" (3.00mm)
- Operating Temperature：-55°C ~ 125°C
- Material Flammability Rating：UL94 V-0
- Contact Finish - Post：Tin
- Mated Stacking Heights：-
- Ingress Protection：-
- Features：-
- Current Rating (Amps)：3A
- Voltage Rating：-
Headers, Receptacles, Female Sockets datasheet and documents for 803-83-022-10-132101
Headers, Receptacles, Female Sockets Overview
The Preci-Dip 803-83-022-10-132101 is a 22-position socket connector designed for through-hole PCB mounting. It features a 0.100 inch (2.54mm) pitch and double-row configuration. The contacts are gold-plated brass with a 10.0µin thickness, ensuring reliable conductivity. Rated for 3A at 150VDC, it operates within -55°C to 125°C. The housing is black PCT with UL94 V-0 flammability rating.
Headers, Receptacles, Female Sockets Feature Summary
- Double-row socket design for high-density interconnects
- Gold-plated contacts for corrosion resistance
- Through-hole solder tail termination
- PCT insulation material for thermal stability
Headers, Receptacles, Female Sockets Applications
- Industrial control systems
- Consumer electronics assemblies
- Telecommunications equipment
- Automotive circuit boards
Headers, Receptacles, Female Sockets Procurement Notes
Verify the specific suffix '132101' matches your board layout requirements. Confirm that the gold plating specification aligns with your environmental durability needs. Ensure the double-row footprint corresponds to the manufacturer's CAD data before finalizing procurement orders.
Headers, Receptacles, Female Sockets Selection Notes
Select this model when a 22-position double-row socket is required. Choose over single-row variants if space efficiency is critical. Verify compatibility with mating pin headers of matching pitch. Consider the operating temperature range for harsh environment applications.
Headers, Receptacles, Female Sockets Part Context
This component belongs to the Preci-Dip 803 series of straight socket connectors. It shares the standard 2.54mm pitch family characteristics but differs in position count and contact finish. It complements the 803-83-024-10-132101 variant which offers 24 positions.
Headers, Receptacles, Female Sockets Replacement Considerations
Direct substitutes include other 22-position double-row sockets from Preci-Dip with identical 2.54mm pitch. Verify mechanical dimensions and electrical ratings match exactly. Cross-reference with generic 2.54mm socket connectors only if pinout and form factor are confirmed compatible.
