803-83-056-30-002101

$6.97

Description：CONN SOCKET 56POS 0.1 GOLD SMD
Series：803
Mfr：Preci-Dip
Package：Bulk

SKU:48efe1d157d2 Category: Headers, Receptacles, Female Sockets Brand: Preci-Dip

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

803-83-056-30-002101 is listed in the Headers, Receptacles, Female Sockets range at ChipApex. The manufacturer field lists Preci-Dip. Its product description is CONN SOCKET 56POS 0.1 GOLD SMD. Review the specifications below when checking this part for your BOM.

Headers, Receptacles, Female Sockets specifications for 803-83-056-30-002101

Description：CONN SOCKET 56POS 0.1 GOLD SMD
Series：803
Mfr：Preci-Dip
Package：Bulk
Connector Type：Socket
Contact Type：Female Socket
Style：Board to Board
Number of Positions：56
Number of Positions Loaded：All
Pitch - Mating：0.100" (2.54mm)
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：29.5µin (0.75µm)
Insulation Color：Black
Insulation Height：0.220" (5.60mm)
Contact Length - Post：-
Operating Temperature：-55°C ~ 125°C
Material Flammability Rating：UL94 V-0
Contact Finish - Post：Tin
Mated Stacking Heights：-
Ingress Protection：-
Features：-
Current Rating (Amps)：3A
Voltage Rating：-

Headers, Receptacles, Female Sockets datasheet and documents for 803-83-056-30-002101

803-83-056-30-002101

Headers, Receptacles, Female Sockets Overview

The Preci-Dip 803-83-056-30-002101 is a 56-position IC DIP socket designed for through-hole mounting. It features a dual-in-line package configuration with a 0.100-inch (2.54mm) pin spacing and a 0.600-inch row pitch. The mating contacts are gold-plated to ensure reliable signal transmission, while the termination pins utilize tin plating for soldering compatibility. Constructed from glass-reinforced PCT insulation, this component supports an operating temperature range of -55°C to 125°C and meets UL94 V-0 flammability standards.
