803-87-070-66-001101

Headers, Receptacles, Female Sockets Overview

The Preci-Dip 803-87-070-66-001101 is a 70-position female socket connector from the 803 series, designed for board-to-board applications. It features a 2.54 mm (0.100 inch) pitch and utilizes through-hole termination for secure PCB mounting. The contacts are gold-plated to ensure reliable signal transmission and corrosion resistance. Rated for 150V and operating within a temperature range of -55°C to +125°C, this component supports high-density interconnections in demanding electronic environments.

Headers, Receptacles, Female Sockets Feature Summary

• Gold-plated contacts provide durable electrical connections with enhanced corrosion resistance.
• Through-hole mounting ensures stable mechanical attachment to printed circuit boards.
• Double-row configuration enables high-density pin arrangements within compact footprints.

Headers, Receptacles, Female Sockets Applications

• High-density board-to-board interconnects
• Industrial control system modules
• Telecommunications equipment backplanes

Headers, Receptacles, Female Sockets Procurement Notes

Verify that the specific part number matches the required contact count and plating specifications before integration. Confirm that the manufacturing date code aligns with project requirements. Ensure compatibility with mating header dimensions and PCB hole tolerances. Cross-reference official datasheets for any recent design revisions or environmental compliance updates prior to final procurement approval.

Headers, Receptacles, Female Sockets Selection Notes

Select this model when a 70-pin female receptacle with gold plating is required for rigid board-to-board connections. The 2.54 mm pitch suits standard industrial spacing needs. Consider the through-hole installation method if surface-mount alternatives are unsuitable for the mechanical stress profile. Verify thermal ratings against the operational environment to ensure reliability under extreme conditions.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Preci-Dip 803 series, which specializes in double-row female sockets for robust electronic assemblies. The series is characterized by its standardized 2.54 mm pitch and versatile mounting options. These connectors are engineered for applications requiring consistent performance and long-term durability in complex multi-layer circuit designs.

Headers, Receptacles, Female Sockets Replacement Considerations

Public confirmed substitute part numbers: None available.
