803-87-100-10-004101

Headers, Receptacles, Female Sockets Overview

The Preci-Dip 803-87-100-10-004101 is a straight socket connector designed for through-hole mounting. It features 100 positions arranged in a double-row configuration with a 0.100-inch (2.54mm) pitch. The contacts are gold-plated to ensure reliable signal transmission, while the housing is constructed from durable insulating materials rated for UL94 V-0 flammability. This component supports standard DIP integration and operates within a temperature range of -55°C to 125°C.

Headers, Receptacles, Female Sockets Feature Summary

• Double-row straight socket design for high-density board connections
• Gold-plated contacts for enhanced conductivity and corrosion resistance
• Through-hole termination method for secure PCB mounting

Headers, Receptacles, Female Sockets Applications

• DIP IC socketing applications
• High-density board-to-board interconnects
• Industrial control system interfaces

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific pin count and row configuration against schematic requirements before ordering. Confirm that the gold plating specification meets the environmental durability needs of the target application. Ensure the through-hole footprint matches the PCB layout dimensions precisely to avoid assembly issues.

Headers, Receptacles, Female Sockets Selection Notes

Select this model when a high-pin-count, double-row female connector is required for through-hole implementation. The 2.54mm pitch ensures compatibility with standard DIP packages. Consider the operating temperature range and UL94 V-0 rating if the environment involves thermal stress or strict fire safety regulations.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Preci-Dip 803 series, which specializes in straight socket connectors. The series offers various position counts and row configurations to accommodate different density requirements. The 803-87 variant specifically denotes the double-row straight style with solder tail termination.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes must match the 100-position, double-row, 2.54mm pitch specification. Verify that alternative manufacturers offer identical gold contact plating and through-hole termination styles to maintain mechanical and electrical compatibility.
