804-V3-084-6B-002101

Headers, Male Pins Overview

The Preci-Dip 804-V3-084-6B-002101 is a board-to-board header connector featuring 84 positions with a 0.100-inch (2.54mm) mating pitch. It utilizes a three-row configuration and employs through-hole, right-angle mounting for secure PCB attachment. The contacts are constructed from brass with tin plating on the tail and gold plating on the mating interface, ensuring reliable conductivity. Rated for 3A at 150VDC, this component operates within a temperature range of -55°C to 125°C. The housing is made of black PCT polyester reinforced with glass fiber, meeting UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Three-row right-angle header design for high-density interconnections
• Gold-plated mating contacts for enhanced signal integrity
• Through-hole termination with push-pull locking mechanism
• Glass-fiber reinforced PCT insulation for thermal stability

Headers, Male Pins Applications

• High-density board-to-board connections in industrial electronics
• Signal routing in telecommunications equipment
• Interconnection modules in automotive control units

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to confirm contact plating thickness and material specifications. Ensure the selected variant matches the required row count and pin configuration for the target application. Cross-reference environmental compliance certifications such as RoHS and REACH status prior to final procurement approval.

Headers, Male Pins Selection Notes

Select this connector when a high-pin-count, three-row header is required for vertical space-constrained designs. The right-angle orientation facilitates compact stacking arrangements. Verify that the mating pitch and contact length align with the corresponding socket or cable assembly specifications to ensure proper engagement and mechanical stability.

Headers, Male Pins Part Context

This component belongs to the Preci-Dip 804 series, which specializes in high-reliability board-to-board interconnects. The series offers various configurations including different row counts and mounting styles. The 804-V3 designation indicates a specific variant within this family, characterized by its particular pin arrangement and termination style suitable for demanding electronic environments.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult the manufacturer's official cross-reference guide for compatible alternatives if sourcing constraints exist.

Headers, Male Pins FAQ

What is the rated current and voltage for this connector?

The connector is rated for 3 Amperes at 150 Volts DC.

Does this connector include a shroud?

No, this specific model is supplied without a shroud.
