Headers, Male Pins Overview

The Preci-Dip 804-V3-093-12-002101 is a vertical rectangular connector header designed for through-hole mounting. It features 93 positions arranged in three rows with a 0.100 inch (2.54mm) pitch. The connector utilizes male pin contacts made of brass, plated with gold on the mating surface and tin on the tail. Rated for 3A current and 150VDC voltage, it operates within a temperature range of -55°C to 125°C. The housing is constructed from black PCT material rated UL94 V-0.

Headers, Male Pins Feature Summary

• Three-row vertical header configuration for high-density board-to-board connections
• Gold-plated contact surfaces ensure reliable signal transmission
• Push-pull locking mechanism secures mating engagement

Headers, Male Pins Applications

• Industrial control systems requiring robust interconnects
• Communication equipment backplanes
• Medical device internal circuitry

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against official Preci-Dip documentation to confirm plating thickness and insulation height specifications. Ensure compatibility with mating socket connectors regarding row alignment and pitch dimensions. Confirm RoHS compliance status if required by project regulations before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a high-pin-count vertical header is necessary for space-constrained applications. The three-row design maximizes connection density while maintaining standard 2.54mm spacing. Consider the push-pull locking feature for applications requiring secure mechanical retention during vibration or thermal cycling events.

Headers, Male Pins Part Context

This part belongs to the Preci-Dip 804 series of rectangular connectors. The series offers various position counts and row configurations to suit different connectivity requirements. Preci-Dip manufactures these components using precision machining techniques to ensure consistent dimensional accuracy and electrical performance across the product line.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 93-position count, three-row layout, and 2.54mm pitch. Verify that alternative headers maintain identical contact plating specifications and locking mechanisms to ensure functional interchangeability without redesigning the PCB footprint.
