805-87-075-10-001101

Headers, Receptacles, Female Sockets Overview

The Preci-Dip 805-87-075-10-001101 is a 75-position socket connector from the 805 series. It features a 2.54 mm (0.100 inch) pitch and utilizes gold-plated contacts for reliable signal transmission. Designed for through-hole termination, this component supports solder mounting on printed circuit boards. The connector is rated for standard voltage applications and operates within typical industrial temperature ranges.

Headers, Receptacles, Female Sockets Feature Summary

• Provides 75 contact positions in a single row configuration
• Utilizes gold plating on contact surfaces for enhanced conductivity
• Supports direct through-hole soldering to PCB substrates

Headers, Receptacles, Female Sockets Applications

• High-density electronic assembly interconnections
• Industrial control board signal routing
• General-purpose circuit board socketing

Headers, Receptacles, Female Sockets Procurement Notes

Verify the exact pin count matches the seventy-five position requirement before integration. Confirm that the gold plating specification aligns with your corrosion resistance needs. Ensure the through-hole footprint dimensions are compatible with your PCB design rules. Check RoHS3 compliance status if environmental regulations apply to your specific manufacturing region or end-use product.

Headers, Receptacles, Female Sockets Selection Notes

Select this model when a high-contact-count single-row socket is required. The 2.54 mm pitch is standard for many legacy and general-purpose systems. Gold plating offers superior performance over tin in environments requiring low contact resistance. Consider the physical height and board clearance requirements associated with through-hole sockets during mechanical layout planning.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Preci-Dip 805 series of single-in-line sockets. The series is characterized by its robust construction and standardized spacing. It serves as a critical interface between integrated circuits or other components and the main system board. The part number indicates specific variations in contact count and termination style within the broader family.

Headers, Receptacles, Female Sockets Replacement Considerations

Cross-reference with other 805-series variants for different pin counts. Verify compatibility with mating headers from the same manufacturer. Ensure substitute parts maintain the same 2.54 mm pitch and gold contact finish to guarantee electrical continuity.
