807-022-555-201 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 22POS 0.156. Review the specifications below when checking this part for your BOM.
Edgeboard Connectors specifications for 807-022-555-201
- Description：CONN EDGE DUAL FMALE 22POS 0.156
- Series：807
- Mfr：EDAC Inc.
- Package：Box
- Card Type：Non Specified - Dual Edge
- Gender：Female
- Number of Positions/Bay/Row：11
- Number of Positions：22
- Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
- Number of Rows：2
- Pitch：0.156" (3.96mm)
- Read Out：Dual
- Features：Card Extender
- Mounting Type：Board Edge, Straddle Mount
- Termination：Solder
- Contact Material：Copper Alloy
- Contact Finish：Gold
- Contact Finish Thickness：10.0µin (0.25µm)
- Contact Type：Semi Bellows
- Color：Green
- Flange Feature：-
- Operating Temperature：-40°C ~ 125°C
Edgeboard Connectors datasheet and documents for 807-022-555-201
Edgeboard Connectors Overview
The EDAC 807-022-555-201 is a standard high-temperature card edge connector receptacle featuring 22 positions with a 3.96 mm pitch. It utilizes gold-plated copper alloy contacts and a diallyl phthalate insulator, rated for 5 A current and 5 GOhms insulation resistance. Designed for through-hole right-angle mounting, it accommodates 1.57 mm board thicknesses within a -40 C to +125 C operating range.
Edgeboard Connectors Feature Summary
- High-temperature operational capability suitable for demanding environments
- Gold-plated contacts ensure reliable signal transmission
- Right-angle through-hole mounting facilitates compact PCB integration
Edgeboard Connectors Applications
- Industrial control systems requiring thermal stability
- High-temperature electronic assemblies
- Ruggedized communication equipment
Edgeboard Connectors Procurement Notes
Verify the specific contact code and tail bend configuration against the official datasheet to ensure mechanical compatibility with the target daughter board. Confirm that the 1.57 mm board thickness requirement aligns with the design specifications before finalizing procurement decisions.
Edgeboard Connectors Selection Notes
Select this component when high-temperature performance and right-angle connectivity are required. Ensure the application supports the 3.96 mm pitch and 22-position count. Verify that the through-hole mounting style fits the assembly constraints and that the operating temperature range meets environmental demands.
Edgeboard Connectors Part Context
This part belongs to the EDAC 807 High Temp Series, designed for robust performance in elevated temperatures. The series offers various position counts and configurations, providing standardized solutions for card edge applications where thermal resilience and reliable electrical connections are critical for system integrity.
Edgeboard Connectors Replacement Considerations
Consult the official EDAC documentation for confirmed substitute part numbers. Cross-reference pin counts, pitch dimensions, and mounting styles to ensure functional equivalence without compromising thermal or electrical specifications.
