830-10-035-40-001101

Headers, Male Pins Overview

The Preci-Dip 830-10-035-40-001101 is a single-row header connector featuring 35 positions with a 2.00mm pitch. It utilizes surface-mount technology in a right-angle configuration for board-to-board applications. The contacts are gold-plated brass pins, while the housing is constructed from black liquid crystal polymer (LCP) reinforced with glass fiber. Rated for 3A current and 150VDC voltage, it operates within a temperature range of -55°C to 125°C and meets UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Right-angle surface mount design facilitates compact PCB integration
• Gold-plated brass contacts ensure reliable signal transmission
• High-temperature LCP insulation supports demanding thermal environments

Headers, Male Pins Applications

• Board-to-board interconnections
• Industrial control systems
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific contact plating material against official datasheets, as variations exist within the 830 series. Confirm that the right-angle SMD footprint matches the target PCB layout. Ensure compliance with RoHS directives if required by the end product specifications.

Headers, Male Pins Selection Notes

Select this component when a high-density, right-angle connection is necessary. Compare pin counts and pitch requirements against alternative headers. Consider the mechanical stability of surface-mount joints versus through-hole options for vibration resistance.

Headers, Male Pins Part Context

This part belongs to the Preci-Dip 830 series of rectangular connectors. The series offers various row configurations and mounting styles. This specific model represents a high-pin-count variant designed for dense circuit layouts requiring robust electrical performance.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 35-position, 2.00mm pitch right-angle headers from Preci-Dip or equivalent manufacturers. Verify mechanical dimensions and electrical ratings before substitution.
