830072546

Crystals Overview

The Würth Elektronik part number 830072546 is a surface-mount crystal oscillator from the WE-XTAL series. It operates at a fundamental frequency of 48.0 MHz with a load capacitance of 10 pF. The component utilizes a 4-SMD, no lead package with dimensions of 2.0 mm by 1.6 mm. Frequency tolerance is specified as ±15 ppm or ±20 ppm depending on source documentation. Equivalent Series Resistance (ESR) is rated at 60 ohms. The device is designed for direct mounting on printed circuit boards.

Crystals Feature Summary

• Surface-mount configuration for automated assembly
• Fundamental mode operation at 48 MHz
• Compact 2.0 x 1.6 mm footprint

Crystals Applications

• Clock generation for microcontrollers
• Timing reference for communication interfaces
• Digital signal processing circuits

Crystals Procurement Notes

Verify the specific frequency tolerance requirement against official datasheets, as sources indicate variations between ±15 ppm and ±20 ppm. Confirm the package type matches the target PCB land pattern. Ensure the load capacitance aligns with the host circuit design requirements before procurement.

Crystals Selection Notes

Select this component when a precise 48 MHz timing source is required in a minimal space-constrained environment. Evaluate the ESR specifications against the oscillator circuit's drive level constraints. Consider the thermal stability characteristics if the application operates in extreme temperature ranges.

Crystals Part Context

This part belongs to the WE-XTAL family of quartz crystals manufactured by Würth Elektronik. These components are engineered for high reliability in consumer electronics and industrial applications. The series offers various frequencies and package sizes to support diverse timing needs.

Crystals Replacement Considerations

Cross-reference with other 48 MHz SMD crystals from Würth Elektronik or compatible manufacturers. Verify that substitute parts match the 2.0x1.6mm footprint, 10pF load capacitance, and equivalent electrical parameters.
