832-80-078-20-001101

$8.37

Description：CONN HEADER R/A 78POS 2MM
Series：832
Mfr：Preci-Dip
Package：Bulk

SKU:515f92412011 Category: Headers, Male Pins Brand: Preci-Dip

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

832-80-078-20-001101 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Preci-Dip. Its product description is CONN HEADER R/A 78POS 2MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 832-80-078-20-001101

Description：CONN HEADER R/A 78POS 2MM
Series：832
Mfr：Preci-Dip
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：78
Number of Rows：2
Row Spacing - Mating：0.079" (2.00mm)
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Through Hole, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.141" (3.60mm)
Contact Length - Post：0.126" (3.20mm)
Overall Contact Length：-
Insulation Height：0.165" (4.20mm)
Contact Shape：Circular
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：-
Contact Finish - Post：Tin
Contact Material：Brass
Insulation Material：Liquid Crystal Polymer (LCP), Glass Filled
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：150VDC

Headers, Male Pins datasheet and documents for 832-80-078-20-001101

832-80-078-20-001101

Headers, Male Pins Overview

The Preci-Dip 832-80-078-20-001101 is a right-angle pin header connector designed for board-to-board applications. It features a 2mm (0.079") pitch with 78 positions arranged in two rows. The unit utilizes brass contacts with tin plating and is housed in black, glass-reinforced liquid crystal polymer (LCP). Rated for 150VDC and 3A, it supports a temperature range of -55°C to 125°C. Installation is via through-hole soldering, and the connector employs a push-pull locking mechanism without a shield.

Headers, Male Pins Feature Summary

Right-angle through-hole mounting configuration for compact board integration
Push-pull locking system ensures secure mating stability
High-temperature resistant LCP insulation material rated UL94 V-0

Headers, Male Pins Applications

Board-to-board interconnections
Industrial control systems
Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific part number against official Preci-Dip documentation to confirm current availability and manufacturing status. Ensure that the required pin count and pitch match the design specifications. Check for environmental compliance certifications such as RoHS if applicable to the target market. Confirm that the operating voltage and current ratings align with the circuit requirements before finalizing procurement.

Headers, Male Pins Selection Notes

Select this component when a high-density, right-angle connection is required with a 2mm pitch. The dual-row layout maximizes contact density within a limited footprint. Consider the thermal resistance of the LCP material for environments exceeding standard temperatures. Verify that the push-pull retention method suits the mechanical constraints of the enclosure design.

Headers, Male Pins Part Context

This connector belongs to the Preci-Dip 832 series, which focuses on high-density rectangular headers. The series offers various pin counts and orientations to support diverse electronic packaging needs. The 832-80 base designation indicates the specific family characteristics regarding pitch and row configuration.
