833-012-558-812

Edgeboard Connectors Overview

The EDAC Inc. 833-012-558-812 is a standard card edge connector featuring 12 positions arranged in a dual female configuration. It utilizes a 0.156-inch (3.96 mm) contact pitch and supports a maximum board thickness of 1.57 mm. The component employs solder pin termination for secure attachment and operates at a current rating of 3 A. Constructed with copper alloy contacts plated in gold, the housing is made from diallyl phthalate (DAP). Designed for panel mounting at a right angle, this series 833 connector ensures reliable electrical interconnection.

Edgeboard Connectors Feature Summary

• Dual row female contact configuration for double-sided card insertion
• Gold-plated copper alloy contacts ensure corrosion resistance and stable conductivity
• Right-angle panel mount design facilitates structured spatial integration
• Diallyl phthalate insulator provides robust mechanical stability

Edgeboard Connectors Applications

• Industrial control system interface connections
• Medical equipment signal transmission modules
• Telecommunications hardware backplane assembly
• Automotive electronic unit interconnects

Edgeboard Connectors Procurement Notes

Verify the complete part number including all suffix digits to ensure exact specification matching. Confirm that the required contact count and pitch align with the target PCB design. Check manufacturer documentation for specific plating thickness requirements and environmental ratings. Ensure panel mounting orientation matches the mechanical layout constraints before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this model when a dual-row female connection is required for right-angle panel installation. The 0.156-inch pitch suits applications needing moderate density without excessive miniaturization. Verify compatibility with the target PCB edge thickness and soldering process capabilities. Consider the DAP material properties for environmental exposure limits during operational deployment.

Edgeboard Connectors Part Context

This component belongs to the EDAC Series 833 family of standard card edge connectors. The series offers various position counts and mounting styles while maintaining consistent 0.156-inch spacing. It serves as a foundational interconnect solution within EDAC's broader portfolio of industrial and commercial connector systems designed for durable performance.

Edgeboard Connectors Replacement Considerations

Cross-reference compatible parts within the EDAC 833 series that share identical pitch and row configuration. Verify mechanical dimensions and terminal type equivalence before substituting. Consult official EDAC interchangeability guides for validated alternative part numbers.
