8413601SA

Overview

The Texas Instruments 8413601SA is an octal D-type flip-flop with a master reset function, housed in a 20-pin Ceramic Flat Pack (CFP) package. It operates within a temperature range of -55°C to 125°C and features TTL-compatible non-inverted outputs. The device supports a maximum clock frequency of 30 MHz and exhibits a maximum propagation delay of 20 ns at 5V with a 50pF load. Static current consumption is specified at 29 mA, while output drive capabilities reach 24 mA for low state and -2.6 mA for high state.

Feature Summary

• Octal configuration providing eight independent D-type storage elements in a single package
• Integrated master reset functionality for simultaneous clearing of all flip-flops
• TTL-compatible non-inverted outputs ensuring direct interface with standard logic circuits
• Extended industrial temperature rating suitable for harsh environmental conditions

Applications

• High-reliability military and aerospace digital systems requiring extended temperature operation
• Industrial control systems demanding robust data storage and processing
• Test and measurement equipment utilizing TTL-compatible logic interfaces
• Communication infrastructure components operating in extreme thermal environments

Procurement Notes

Verify the specific ordering suffix against official Texas Instruments documentation to confirm exact package variant and temperature grade. Ensure compatibility with existing ceramic flat pack footprint requirements. Confirm that the 20-pin CFP mechanical dimensions align with the target PCB design constraints before finalizing procurement orders.

Selection Notes

Select this component when an octal D-type flip-flop with integrated master reset is required for TTL-based designs. Consider the 20-CFP package for applications necessitating high thermal stability and radiation hardness. Evaluate the 30 MHz clock speed and 20 ns propagation delay against system timing requirements to ensure adequate performance margins.

Part Context

This part belongs to the broader family of octal D-type flip-flops manufactured by Texas Instruments. It shares functional similarities with other SN54/SN74 series devices but distinguishes itself through the specific CFP packaging and extended temperature range capabilities designed for specialized industrial and defense applications.

Replacement Considerations

Consult official cross-reference guides for equivalent parts. Verify pinout compatibility and electrical specifications before substituting with alternative manufacturers' offerings.
