842-011-544-107

Edgeboard Connectors Overview

The EDAC Inc. 842-011-544-107 is a standard card edge connector receptacle designed for through-hole mounting with a right-angle orientation. It features 35 positions with a contact spacing of 2.54 mm (0.100 inch) and a row spacing of 5.08 mm (0.200 inch). The connector accepts printed circuit boards with a nominal thickness of 1.57 mm (0.062 inch). The contacts are gold-plated, and the insulator body is high-profile green.

Edgeboard Connectors Feature Summary

• High-profile insulator body design
• Gold-plated contacts for reliable signal transmission
• Right-angle through-hole mounting style

Edgeboard Connectors Applications

• Medical interconnect solutions
• Agricultural technology equipment
• Industrial control systems

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix to ensure compatibility with required board thickness and contact plating specifications. Confirm that the right-angle configuration aligns with the mechanical layout constraints of the target assembly. Cross-reference the manufacturer's latest documentation to validate current RoHS compliance status and any potential supply chain restrictions before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this component when a right-angle connection is required for single-edge board insertion. Ensure the host PCB accommodates the specified 1.57 mm thickness tolerance. Verify that the 2.54 mm pitch matches the mating card edge dimensions. Consider the high-profile body height for adequate clearance within the enclosing chassis or housing structure during system integration.

Edgeboard Connectors Part Context

This part belongs to the EDAC 842 series of standard card edge connectors. The series offers various position counts and mounting styles to support diverse electronic interconnection needs. EDAC specializes in robust connector solutions for demanding environments, including medical and agricultural applications, ensuring durability and consistent performance across their product line.

Edgeboard Connectors Replacement Considerations

Direct substitutes include parts from the same family with identical electrical and mechanical parameters, such as the 842-035-558-112 for similar positioning requirements. Always verify pin count and pitch compatibility before substitution.
