850-10-014-10-001101

Headers, Male Pins Overview

Preci-Dip part number 850-10-014-10-001101 is a single-row male pin header connector from the 850 series. It features a 1.27 mm (0.050 inch) pitch and contains 14 positions. The connector is designed for right-angle through-hole mounting, allowing for perpendicular board-to-board connections. It utilizes gold-plated contacts made of brass to ensure reliable signal transmission. The housing is constructed from black glass-reinforced PCT material, rated UL94 V-0 for flammability. Electrical ratings include a current capacity of 1A and a voltage rating of 150VDC. The operating temperature range spans from -55°C to +125°C.

Headers, Male Pins Feature Summary

• Right-angle configuration enables compact vertical board stacking
• Gold-plated brass contacts provide corrosion resistance and stable conductivity
• Glass-reinforced PCT insulation ensures high thermal stability and mechanical strength
• Through-hole termination offers robust solder joint integrity

Headers, Male Pins Applications

• Board-to-board interconnections in electronic assemblies
• Industrial control systems requiring right-angle routing
• Consumer electronics with space-constrained layouts
• Test and measurement equipment interfaces

Headers, Male Pins Procurement Notes

Verify that the specific ordering suffix matches the required contact plating and orientation. Confirm that the right-angle form factor aligns with the PCB layout constraints. Ensure the 1.27mm pitch corresponds to the mating connector specifications. Check for RoHS compliance documentation if environmental regulations apply to the final product assembly.

Headers, Male Pins Selection Notes

Select this component when a right-angle connection is necessary to save vertical space or route signals perpendicularly. The 14-position count suits moderate density applications. Verify that the 1A current rating meets the circuit requirements. Consider the 150VDC limit for electrical isolation needs. Ensure the through-hole process is compatible with the manufacturing capabilities.

Headers, Male Pins Part Context

This part belongs to the Preci-Dip 850 series, which specializes in high-density board-to-board connectors. The series offers various row counts and pitches. The 850-10 variant specifically denotes the right-angle orientation within the standard 850 family. It complements matching socket connectors for complete interconnect solutions.

Headers, Male Pins Replacement Considerations

No direct substitute part numbers are confirmed in the provided documentation. Cross-reference with other 1.27mm right-angle headers only if mechanical and electrical parameters match exactly.
