850-10-049-40-251101

Headers, Male Pins Overview

The Preci-Dip 850-10-049-40-251101 is a surface-mount right-angle header with 49 positions and a 1.27mm pitch. It features single-row, board-to-board style construction with no shroud. The contacts are brass pins with gold plating (10.0µin thickness) for both mating and post surfaces. Rated at 1A and 150VDC, it operates within -55°C to 125°C. The insulator is black PCT/GF, UL94 V-0 rated, with an insulation height of 0.087 inches.

Headers, Male Pins Feature Summary

• Surface-mount right-angle design facilitates automated pick-and-place assembly
• Gold-plated screw-machined brass contacts ensure reliable signal transmission
• Glass-filled polyester insulator provides high thermal stability and flame resistance

Headers, Male Pins Applications

• Data signal interconnects in compact electronic modules
• Control circuit board-to-board connections
• Power distribution headers in low-current applications

Headers, Male Pins Procurement Notes

Verify the specific part number against official Preci-Dip documentation to confirm current availability and compliance status. Ensure that the ordering suffix matches the required contact finish and packaging specifications. Cross-reference the manufacturer's latest datasheet for any updates on environmental certifications or RoHS compliance before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a high-density, right-angle surface-mount header is required for 1.27mm pitch applications. The 49-position count suits complex multi-signal interfaces. Consider the 1A current rating and 150VDC voltage limit for electrical safety. The right-angle orientation is optimal for space-constrained vertical stacking or edge-connecting PCB layouts.

Headers, Male Pins Part Context

This connector belongs to the Preci-Dip 850 series, which specializes in precision screw-machined contacts. The series is known for high reliability in harsh environments. The 850-10 variant specifically denotes a standard header configuration. Preci-Dip manufactures these components under ISO 9001 and EN 9100 standards, ensuring consistent quality for industrial and commercial electronics.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 1.27mm pitch, 49-position count, SMD right-angle form factor, and gold-plated brass contact material. Verify that alternative headers share the same UL94 V-0 insulation rating and 1A/150VDC electrical ratings. Ensure mechanical compatibility with existing PCB footprints and mating connectors.
