850-40-049-10-001000

Headers, Male Pins Overview

The Mill-Max 850-40-049-10-001000 is a vertical pin header connector from the 850 series, designed for board-to-board interconnection. It features 49 positions with a 1.27mm (0.050 inch) pitch and single-row configuration. The component utilizes through-hole termination with solder cup contacts. Key physical specifications include a contact length of 0.118 inches (3.00mm) for mating and 0.114 inches (2.90mm) for the post. The housing provides an insulation height of 0.087 inches (2.20mm).

Headers, Male Pins Feature Summary

• Vertical orientation design facilitates standard PCB mounting configurations.
• Push-pull locking mechanism ensures secure connection stability.
• Gold-plated contacts provide reliable electrical conductivity and corrosion resistance.

Headers, Male Pins Applications

• High-density board-to-board interconnects in electronic assemblies.
• Test and measurement equipment requiring robust signal paths.
• Industrial control systems utilizing precision-machined components.

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm the exact contact plating thickness and material composition, as variations exist within the 850 series. Ensure compatibility with mating receptacles regarding pin count and pitch. Confirm that the vertical form factor aligns with the mechanical constraints of the target assembly. Cross-reference the manufacturer datasheet for precise dimensional tolerances before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this part when a high-pin-count vertical header is required for dense circuit layouts. The 1.27mm pitch allows for significant I/O density within a limited footprint. Consider the through-hole mounting style for applications requiring strong mechanical retention. Evaluate the push-pull locking feature if vibration resistance is a critical design requirement compared to standard friction-fit headers.

Headers, Male Pins Part Context

This component belongs to the Mill-Max 850 series, which specializes in high-reliability precision-machined interconnects. The series is recognized for its durability and performance in demanding environments. Mill-Max Manufacturing Corp. has produced these components since 1971, establishing a reputation for quality in the global electronics supply chain. This specific model represents a standard vertical variant within that extensive product line.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 49-position count, 1.27mm pitch, and vertical orientation. Verify that alternative headers support the same through-hole termination method and push-pull locking mechanism. Ensure the replacement part maintains identical insulation height and contact length specifications to guarantee proper mating with existing connectors.
