852-10-066-20-001000

Headers, Male Pins Overview

The Mill-Max 852-10-066-20-001000 is a right-angle pin header connector designed for through-hole mounting. It features 66 positions arranged in a single row with a 0.050-inch (1.27mm) pitch. The contacts are gold-plated copper alloy, providing reliable conductivity and corrosion resistance. This component is engineered for high-density board-to-board interconnections.

Headers, Male Pins Feature Summary

• Right-angle configuration facilitates compact PCB layout designs
• Gold-plated contacts ensure durable electrical performance
• Through-hole termination method provides secure mechanical attachment

Headers, Male Pins Applications

• High-density board-to-board interconnects
• Compact electronic assembly integration
• Precision-machined interconnection systems

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Mill-Max documentation to confirm exact plating thickness and material specifications. Ensure that the right-angle orientation matches the target PCB footprint requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when space constraints necessitate a right-angle connection profile. The 0.050-inch pitch supports high pin counts within limited board areas. Confirm compatibility with mating socket connectors regarding contact length and insulation height.

Headers, Male Pins Part Context

This part belongs to the Mill-Max standard pin header series, known for precision-machined interconnect components. The manufacturer specializes in high-reliability connectors for demanding industrial and commercial applications, emphasizing durability and consistent electrical performance.

Headers, Male Pins Replacement Considerations

Consult official Mill-Max cross-reference guides for verified substitutes. Generic replacements may differ in contact geometry or plating specifications, potentially affecting fit and reliability.
