Headers, Male Pins Overview

The Preci-Dip 852-10-072-10-002101 is a card edge connector designed for board-to-board applications. It features 72 contacts arranged in two rows with a 0.050-inch (1.27mm) pitch. The connector utilizes male straight pins with solder terminals and a black insulator. It is rated for 1A current and 150VDC voltage, operating within a temperature range of -55°C to 125°C. The housing material is PCT polyester reinforced with glass fiber, meeting UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Designed for high-density board-to-board interconnections using a narrow 1.27mm pitch.
• Features male straight pins with solder terminals for secure PCB mounting.
• Constructed with glass-fiber-reinforced PCT insulation for thermal stability.

Headers, Male Pins Applications

• High-density electronic assemblies requiring narrow profile connections
• Industrial control systems utilizing board-to-board interfaces
• Telecommunications equipment with space-constrained layouts

Headers, Male Pins Procurement Notes

Verify the specific series suffix against official Preci-Dip documentation to confirm terminal plating and contact material specifications. Ensure the ordering part number matches the required pitch and row configuration. Cross-reference environmental certifications such as RoHS compliance with the manufacturer's latest datasheet before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a 1.27mm pitch is required for compact board-to-board designs. Compare the 852 series against other Preci-Dip headers to ensure the straight pin style and solder termination meet assembly constraints. Confirm that the 1A current rating aligns with the electrical load requirements of the target application circuitry.

Headers, Male Pins Part Context

This component belongs to the Preci-Dip 852 series of card edge connectors. It is distinct from the 852-80 variant which shares similar dimensions but may differ in specific contact configurations or plating options. The 852 series is engineered for reliable signal transmission in dense electronic architectures.

Headers, Male Pins Replacement Considerations

Direct substitutes include the 852-80-072-10-002101 if contact plating differences are acceptable. Verify mechanical compatibility and electrical ratings before swapping between series variants to ensure proper fit and function.
