852-10-096-10-001101

Headers, Male Pins Overview

Preci-Dip part number 852-10-096-10-001101 is a 96-position header connector from the 852 series. It features a 1.27 mm pitch and utilizes surface mount termination for PCB integration. The connector supports a rated current of 1A and a voltage of 150V DC. Constructed with brass contacts and glass-filled PCT insulation, it operates within a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Surface mount design for automated assembly
• High-density 96-pin configuration
• Gold-plated contact surfaces

Headers, Male Pins Applications

• Board-to-board interconnections
• High-density electronic assemblies
• Industrial control systems

Headers, Male Pins Procurement Notes

Verify the specific suffix '10' against official Preci-Dip documentation to confirm gold plating specifications. Ensure compatibility with standard SMT reflow profiles. Cross-reference the manufacturer datasheet for precise mechanical dimensions and recommended land pattern details before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when high pin density is required in a compact footprint. The surface mount style eliminates through-hole drilling requirements. Verify that the 1.27 mm pitch aligns with mating connector standards. Confirm thermal resistance ratings meet the operational environment constraints of the target application.

Headers, Male Pins Part Context

This component belongs to the Preci-Dip 852 series, which specializes in high-density board-to-board connectors. The series offers various pin counts and termination styles. This specific model provides a robust solution for modern electronics requiring reliable signal transmission in space-constrained designs.

Headers, Male Pins Replacement Considerations

Compatible mating sockets include Preci-Dip part numbers 851-87-096-10-001101 and 851-87-096-30-001101. Ensure the replacement maintains identical pitch and contact configuration.
