852-40-092-20-001000

Headers, Male Pins Overview

The Mill-Max 852-40-092-20-001000 is a right-angle pin header connector designed for through-hole mounting. It features 92 positions arranged in a single row with a 0.050-inch (1.27mm) pitch. The contacts are made of beryllium copper and finished with gold plating to ensure reliable conductivity. Rated for 3A current at 150VDC, it operates within a temperature range of -55°C to 125°C. The housing utilizes glass-filled polyester, meeting UL94 V-0 flammability standards. This component provides robust interconnection for high-density circuit board applications.

Headers, Male Pins Feature Summary

• Right-angle configuration facilitates compact board-to-board connections
• Gold-plated beryllium copper contacts ensure durable signal integrity
• Through-hole termination supports secure PCB mounting

Headers, Male Pins Applications

• High-density electronic assemblies requiring right-angle routing
• Industrial control systems with space constraints
• Communication equipment internal interconnects

Headers, Male Pins Procurement Notes

Verify the complete part number including suffixes to confirm specific contact finishes and material grades. Ensure compatibility with mating socket specifications regarding pitch and row configuration. Confirm that the right-angle orientation aligns with mechanical assembly requirements and clearance constraints on the target printed circuit board layout.

Headers, Male Pins Selection Notes

Select this model when a single-row, right-angle header is required for 0.050-inch pitch applications. Consider the 92-position count for system interface density needs. Evaluate the gold contact finish against environmental exposure requirements to determine if standard tin alternatives suffice for cost optimization while maintaining necessary corrosion resistance.

Headers, Male Pins Part Context

This component belongs to the Mill-Max 852 series, which specializes in miniature spring-loaded and standard pin headers. The series focuses on high-reliability interconnect solutions for demanding environments. The 852 designation indicates a specific form factor optimized for dense packaging and precise mechanical alignment in modern electronics manufacturing.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 92-position, 0.050-inch pitch right-angle headers from manufacturers such as Preci-Dip or Samtec. Verify that alternative parts match the critical dimensions, current rating, and operating temperature range before integration.
