852-80-044-10-001101

Headers, Male Pins Overview

The Preci-Dip 852-80-044-10-001101 is a 44-position dual-row header connector from the 852 series, designed for board-to-board applications. It features a 1.27 mm (0.050 inch) pitch with straight through-hole termination. The unit utilizes brass contacts with tin plating and a glass-reinforced PCT polyester insulator rated UL94 V-0. Electrical ratings include 1A current capacity and 150V DC voltage, operating within a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Straight orientation design facilitates direct vertical mounting on printed circuit boards.
• Tin-plated brass contacts ensure reliable signal transmission and corrosion resistance.
• Glass-reinforced PCT insulation provides structural stability and high thermal endurance.

Headers, Male Pins Applications

• Board-to-board interconnections in compact electronic assemblies
• Industrial control system interface modules
• Consumer electronics internal wiring harnesses

Headers, Male Pins Procurement Notes

Verify the specific pin count and row configuration against schematic requirements before ordering. Confirm that the straight termination style aligns with the PCB layout constraints. Ensure the tin-plated contact finish meets the environmental exposure standards for the intended application environment.

Headers, Male Pins Selection Notes

Select this model when a low-profile, straight-mount solution is required for dense signal routing. The 1.27mm pitch allows for higher density compared to standard 2.54mm headers. Consider the 1A rating per contact for load calculations and verify compatibility with mating female socket connectors in the same series.

Headers, Male Pins Part Context

This component belongs to the Preci-Dip 852 series, which offers various configurations including right-angle and different pin counts. The series is characterized by its use of durable thermoplastic materials and standardized dimensions suitable for automated assembly processes in modern electronics manufacturing.

Headers, Male Pins Replacement Considerations

Compatible mating sockets include part numbers such as 853-80-044-10-001101 or 853-87-044-10-001101. Verify that any substitute maintains the identical 1.27mm pitch and 44-pin configuration to ensure mechanical fit and electrical continuity.
