87827-430HLF

Headers, Male Pins Overview

The Amphenol ICC (FCI) 87827-430HLF is a BergStik unshrouded vertical header connector designed for board-to-board applications. It features a single row with 30 positions and a 2.54 mm pitch. The contacts are tin-plated phosphor bronze pins rated for 3 A current. Termination is achieved via through-hole soldering with straight mounting. The housing is black thermoplastic, UL 94 V-0 rated, supporting operation from -65 C to +125 C.

Headers, Male Pins Feature Summary

• Unshrouded single-row design for compact board-to-board interconnects
• Tin-plated phosphor bronze male pin contacts for reliable conductivity
• Through-hole termination with straight mounting angle
• Black thermoplastic housing with UL 94 V-0 flammability rating

Headers, Male Pins Applications

• Board-to-board connections in industrial equipment
• Interconnects in instrumentation and measurement devices
• Connections within factory automation systems
• Signal routing in heavy equipment control panels

Headers, Male Pins Procurement Notes

Verify the specific part number suffix against official manufacturer documentation to confirm contact plating and terminal length specifications. Ensure that the ordering requirements align with the manufacturer's current production status and lead time policies before finalizing procurement plans.

Headers, Male Pins Selection Notes

Select this component when a single-row, unshrouded header is required for standard 2.54 mm pitch applications. Confirm that the 3 A current rating and -65 C to +125 C temperature range meet the system's operational demands. Verify compatibility with mating receptacles in the same series.

Headers, Male Pins Part Context

This component belongs to the BergStik 87827 series of headers and wire housings. It is manufactured by Amphenol FCI, providing standardized interconnect solutions for various electronic assemblies. The series offers multiple position counts to accommodate different circuit density requirements.

Headers, Male Pins Replacement Considerations

Consult official cross-reference data for verified substitute part numbers. Ensure any replacement maintains identical pitch, row configuration, and termination style to guarantee mechanical and electrical compatibility.
