Headers, Male Pins Overview

The Molex 87833-1221 is a shrouded header connector featuring a right-angle, through-hole mounting configuration. It provides a 12-position array with a 2.00mm (0.079 inch) pitch. The component utilizes male pins and employs a solder termination method for secure board attachment. Designed within the Milli-Grid series, it supports high-performance applications requiring durability in harsh conditions.

Headers, Male Pins Feature Summary

• Shrouded housing design to ensure correct mating alignment
• Right-angle orientation for compact board layout integration
• Through-hole solder termination for robust mechanical stability

Headers, Male Pins Applications

• High-performance peripheral device connections
• Harsh environment electronic assemblies
• Compact board-to-board interconnects

Headers, Male Pins Procurement Notes

Verify the exact part number suffix against official Molex documentation to confirm pin count and pitch specifications. Ensure compatibility with existing PCB footprint requirements before procurement. Cross-reference datasheets for termination type and housing material properties to validate suitability for the intended operational environment.

Headers, Male Pins Selection Notes

Select this component when a right-angle, 12-position connection is required on a 2.00mm pitch grid. Consider the shrouded design for improved mating reliability compared to open headers. Evaluate the through-hole soldering process against surface-mount alternatives based on assembly capabilities and mechanical stress requirements.

Headers, Male Pins Part Context

This connector belongs to the Molex Milli-Grid family, engineered for reliable signal transmission. The 87833 series specifically addresses space-constrained designs needing durable, right-angle connectivity. It complements other components in the system by providing a stable interface point for peripheral devices.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 12-position count, 2.00mm pitch, right-angle form factor, and shrouded housing. Verify that alternative manufacturers offer identical through-hole termination and male pin configurations to maintain mechanical and electrical continuity.
