882-70-036-20-001101 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Preci-Dip. Its product description is CONN HEADER R/A 36POS 2MM. Review the specifications below when checking this part for your BOM.
Headers, Male Pins specifications for 882-70-036-20-001101
- Description：CONN HEADER R/A 36POS 2MM
- Series：882
- Mfr：Preci-Dip
- Package：Bulk
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.079" (2.00mm)
- Number of Positions：36
- Number of Rows：2
- Row Spacing - Mating：0.079" (2.00mm)
- Number of Positions Loaded：All
- Style：Board to Board
- Shrouding：Unshrouded
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.157" (4.00mm)
- Contact Length - Post：0.110" (2.79mm)
- Overall Contact Length：-
- Insulation Height：0.157" (4.00mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：Flash
- Contact Finish - Post：Gold
- Contact Material：Brass
- Insulation Material：Polyamide (PA), Nylon, Glass Filled
- Features：-
- Operating Temperature：-55°C ~ 125°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：1A
- Voltage Rating：150VDC
Headers, Male Pins datasheet and documents for 882-70-036-20-001101
Headers, Male Pins Overview
The Preci-Dip 882-70-036-20-001101 is a right-angle board-to-board header connector featuring 36 positions arranged in two rows with a 2.00mm (0.079 inch) pitch. It utilizes through-hole termination and includes push-pull locking for secure attachment. The contacts are gold-plated brass pins, while the housing is constructed from black glass-reinforced polyamide rated UL94 V-0. Rated for 1A at 150VDC, it operates within a temperature range of -55°C to 125°C.
Headers, Male Pins Feature Summary
- Push-pull locking mechanism ensures secure board-to-board connection
- Gold-plated brass contacts provide reliable conductivity
- Glass-reinforced polyamide insulation offers thermal stability
Headers, Male Pins Applications
- Board-to-board interconnections
- Electronic device internal wiring
- Industrial control systems
Headers, Male Pins Procurement Notes
Verify the specific part number against official Preci-Dip documentation to confirm pin count, row configuration, and contact plating specifications. Ensure compatibility with mating socket connectors regarding pitch and locking style before procurement.
Headers, Male Pins Selection Notes
Select this component when a 2.00mm pitch right-angle header with push-pull retention is required. Consider the 1A current rating and operating temperature range relative to the application environment. Verify that the PCB layout supports the specified through-hole termination method.
Headers, Male Pins Part Context
This connector belongs to the Preci-Dip 882 series, which specializes in high-density rectangular headers. The series provides various pin counts and configurations designed for robust electronic interconnects requiring secure mechanical locking and consistent electrical performance.
Headers, Male Pins Replacement Considerations
Compatible mating sockets include models such as 883-70-036-10-001101 or 883-70-036-30-001101. Ensure replacement parts match the 2.00mm pitch, 36-position count, and push-pull locking features.
