890-18-007-10-003101

Headers, Male Pins Overview

The Preci-Dip 890-18-007-10-003101 is a single-row card edge connector designed for vertical board-to-board applications. It features seven male contacts with a 0.1-inch (2.54mm) pitch and straight solder terminals. The housing is constructed from black insulator material, providing a secure locking mechanism for stable connections. This component supports surface-mount or through-hole integration depending on the specific tail configuration, ensuring reliable electrical performance in compact electronic assemblies.

Headers, Male Pins Feature Summary

• Single-row male pin configuration for direct board interconnection
• Vertical orientation with straight solder tails for PCB mounting
• Black insulator housing with integrated locking feature

Headers, Male Pins Applications

• Board-to-board interconnects in compact electronics
• Industrial control modules requiring secure locking
• Consumer device internal circuitry connections

Headers, Male Pins Procurement Notes

Verify the exact contact tail length and plating specifications against the official Preci-Dip datasheet before procurement. Confirm that the single-row 7-position layout matches the target PCB footprint. Ensure the locking mechanism type aligns with assembly requirements. Cross-reference the RoHS compliance status with current regulatory standards for the destination market to avoid compliance issues during import or manufacturing.

Headers, Male Pins Selection Notes

Select this model when a low-profile, single-row header with a locking feature is required for vertical mounting. The 0.1-inch pitch suits standard density layouts. Consider the 7-contact count for limited signal paths. Evaluate the straight solder tail design for compatibility with automated placement equipment. Compare against higher row counts if more signals are needed within the same footprint constraints.

Headers, Male Pins Part Context

This part belongs to the Preci-Dip 890 series of rectangular connectors, which specializes in card edge and header solutions. The series offers various row counts and pitch options to accommodate diverse board space limitations. The 890-18 variant specifically denotes single-row headers with straight termination, widely used in general-purpose electronic hardware where reliable mechanical retention is prioritized alongside electrical connectivity.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other single-row 7-position headers with 2.54mm pitch and locking features from Preci-Dip or equivalent manufacturers. Verify identical housing dimensions and terminal geometry to ensure mechanical fit. Check for matching plating thickness and material composition to maintain electrical reliability. Ensure the replacement part maintains the same vertical orientation and solder tail style for seamless PCB integration.
