890-18-022-20-002101

Headers, Male Pins Overview

The Preci-Dip 890-18-022-20-002101 is a rectangular header connector featuring 22 positions in a single row with a 0.100" (2.54mm) pitch. Designed for right-angle through-hole mounting, it utilizes square male pins with gold-plated mating surfaces and tin-plated tails. The unit operates within a temperature range of -55°C to 125°C, rated at 3A and 150VDC, with UL94 V-0 flammability.

Headers, Male Pins Feature Summary

• Right-angle board-to-board interconnection design
• Gold-plated square contact geometry for reliable signal transmission
• Push-pull locking mechanism for secure mating

Headers, Male Pins Applications

• Industrial control system circuit boards
• Consumer electronics internal connections
• Telecommunications equipment interfaces

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Preci-Dip documentation to ensure correct plating thickness and material composition. Confirm that the right-angle orientation matches the PCB layout requirements. Cross-reference the 22-position count to avoid confusion with adjacent series variants.

Headers, Male Pins Selection Notes

Select this component when a right-angle profile is required for space-constrained assemblies. Ensure the PCB hole pattern accommodates the 2.54mm pitch. Verify that the 3A current rating meets the application's electrical load requirements without derating concerns.

Headers, Male Pins Part Context

This part belongs to the Preci-Dip 890 series, which specializes in right-angle headers. It shares the fundamental mechanical interface with other models in the family but differs in pin count and specific tail configuration. The series is engineered for high-density board-to-board applications.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Preci-Dip 890-series headers with identical 2.54mm pitch and right-angle mounting. Verify compatibility with existing mating sockets before substitution.
