892-18-058-10-004101

Headers, Male Pins Overview

The Preci-Dip 892-18-058-10-004101 is a vertical board-to-board header connector from the 892 series. It features 58 positions with a 0.100 inch (2.54mm) pitch and two rows of male pins. Designed for through-hole mounting, it utilizes brass contacts with tin plating on both mating and post surfaces. The housing is constructed from glass-filled polyamide (PA), rated UL94 V-0, and operates within a temperature range of -55°C to 125°C. Electrical ratings include 3A current and 150VDC voltage.

Headers, Male Pins Feature Summary

• Vertical board-to-board interconnection design
• Through-hole termination for secure PCB mounting
• Push-pull locking mechanism for retention
• Tin-plated brass contacts for conductivity

Headers, Male Pins Applications

• Industrial control system interconnects
• Consumer electronics assembly
• Telecommunications equipment connections
• General-purpose circuit board stacking

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Preci-Dip documentation to confirm contact plating and insulation material specifications. Ensure compatibility with mating socket dimensions and verify that the required pin count matches the 58-position configuration. Confirm RoHS compliance status if restricted substances are a project constraint.

Headers, Male Pins Selection Notes

Select this component when a high-density, two-row vertical header is required for through-hole applications. Consider the 0.100-inch pitch for standard spacing needs and the tin-plated contacts for cost-effective general-purpose use. Evaluate the operating temperature range and current rating against circuit requirements before finalizing the selection.

Headers, Male Pins Part Context

This part belongs to the Preci-Dip 892 series of rectangular connectors. The series offers various pin counts and row configurations for board-to-board applications. The 892 series is characterized by its robust polyamide housing and standardized 2.54mm pitch, providing reliable interconnection solutions across multiple electronic industries.

Headers, Male Pins Replacement Considerations

Consult Preci-Dip catalogs for direct substitutes within the 892 series with different pin counts or plating options. Verify mechanical footprint and electrical ratings before substituting with components from other manufacturers.
