Headers, Male Pins Overview

The Preci-Dip 892-80-030-10-002101 is a vertical board-to-board header connector from the 892 series. It features 30 positions with a 0.100 inch (2.54mm) pitch in a single row configuration. The connector utilizes through-hole termination and square pin contacts with tin plating on both mating and tail sections. Constructed with glass-filled polyamide insulation rated UL94 V-0, it supports a maximum current of 3A at 150VDC across an operating temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Vertical board-to-board interconnection design for standard PCB mounting
• Square contact geometry with tin-plated brass terminals for reliable conductivity
• Glass-filled polyamide insulation housing providing UL94 V-0 flame resistance
• Through-hole solder tail termination ensuring secure mechanical attachment

Headers, Male Pins Applications

• Industrial control system circuit boards
• Embedded computing hardware modules
• Consumer electronic device internal connections
• Telecommunications equipment signal routing

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to confirm exact pin count, row configuration, and plating specifications. Ensure compatibility with mating socket connectors regarding pitch and contact geometry. Confirm that the selected variant meets the required thermal and electrical ratings for the target application environment before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a vertical, single-row header with a 2.54mm pitch is required for direct board-to-board connection. Consider the 3A current rating and 150VDC voltage limit to ensure safe operation within the specified temperature range. Verify that the through-hole mounting style aligns with the PCB fabrication capabilities and that the square pin shape matches the intended mating interface requirements.

Headers, Male Pins Part Context

This part belongs to the Preci-Dip 892 series of rectangular connectors, which are designed for high-density interconnect applications. The series offers various configurations including vertical and right-angle orientations with different pin counts. These connectors are widely used in electronics manufacturing where reliable signal transmission and mechanical stability are critical for long-term performance in diverse environmental conditions.
