892-80-060-10-001101

$1.65

Description：CONN HEADER VERT 60POS 2.54MM
Series：892
Mfr：Preci-Dip
Package：Bulk

SKU:52adf4c43d8f Category: Headers, Male Pins Brand: Preci-Dip

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

892-80-060-10-001101 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Preci-Dip. Its product description is CONN HEADER VERT 60POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 892-80-060-10-001101

Description：CONN HEADER VERT 60POS 2.54MM
Series：892
Mfr：Preci-Dip
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：60
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.236" (6.00mm)
Contact Length - Post：0.122" (3.10mm)
Overall Contact Length：0.458" (11.64mm)
Insulation Height：0.100" (2.54mm)
Contact Shape：Square
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：-
Contact Finish - Post：Tin
Contact Material：Brass
Insulation Material：Polyamide (PA), Nylon, Glass Filled
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：150VDC

Headers, Male Pins datasheet and documents for 892-80-060-10-001101

892-80-060-10-001101

Headers, Male Pins Overview

The Preci-Dip 892-80-060-10-001101 is a board-to-board header connector from the 892 series. It features a 2.54 mm pitch with 60 positions arranged in two rows. The component utilizes brass contacts with tin plating and is designed for through-hole mounting. Rated at 3A current and 150VDC voltage, it operates within a temperature range of -55°C to 125°C. The housing is constructed from black glass-filled polyamide (PA) nylon with UL94 V-0 flammability rating.
