894-80-024-10-003101

Headers, Male Pins Overview

The Preci-Dip 894-80-024-10-003101 is a vertical male pin header connector from the 894 series. It features 24 positions with a 0.100 inch (2.54mm) pitch in a single row configuration. Designed for through-hole mounting, it utilizes brass contacts with tin plating on both mating and tail surfaces. The housing is constructed from glass-filled polyamide, rated UL94 V-0, and operates within a temperature range of -55°C to 125°C. Rated at 3A and 150VDC, this board-to-board connector provides reliable electrical interconnection.

Headers, Male Pins Feature Summary

• Vertical board-to-board design with push-pull locking mechanism
• Single row configuration with 0.100 inch (2.54mm) spacing
• Tin-plated brass contacts for corrosion resistance
• Glass-filled polyamide insulation with UL94 V-0 flammability rating

Headers, Male Pins Applications

• General purpose electronic circuit interconnections
• Industrial control system board connections
• Consumer electronics assembly
• Telecommunications equipment interfaces

Headers, Male Pins Procurement Notes

Verify the specific part number against manufacturer documentation to confirm current availability and lead times. Ensure that the tin-plated contact finish meets the environmental requirements of the target application. Confirm that the through-hole termination method aligns with the manufacturing process capabilities. Check for any RoHS or REACH compliance certifications required by the destination market regulations before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a single-row vertical header with a 2.54mm pitch is required. The 24-position count suits applications needing moderate I/O density. The tin-plated contacts are suitable for standard signal applications without gold plating requirements. Verify that the 3A current rating and 150VDC voltage rating exceed the operational loads. Ensure the PCB layout accommodates the specified overall contact length and insulation height dimensions.

Headers, Male Pins Part Context

This connector belongs to the Preci-Dip 894 series, which offers various position counts and row configurations. The series is characterized by its robust mechanical design and standardized 2.54mm pitch. Similar parts in the family include different pin counts such as 54 positions, maintaining consistent electrical and mechanical specifications while varying the physical footprint to suit diverse board space constraints.

Headers, Male Pins Replacement Considerations

Direct substitutes may include other 24-position, single-row headers with identical 2.54mm pitch and through-hole termination. Verify compatibility regarding contact material, plating type, and insulation flammability rating. Ensure that the mating socket connectors match the pin diameter and locking mechanism specifications to guarantee proper engagement and retention force.
