894-80-105-10-002101

$4.76

Description：CONN HEADER VERT 105POS 2.54MM
Series：894
Mfr：Preci-Dip
Package：Bulk

SKU:4005c20fa349 Category: Headers, Male Pins Brand: Preci-Dip

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

894-80-105-10-002101 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Preci-Dip. Its product description is CONN HEADER VERT 105POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 894-80-105-10-002101

Description：CONN HEADER VERT 105POS 2.54MM
Series：894
Mfr：Preci-Dip
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：105
Number of Rows：3
Row Spacing - Mating：0.100" (2.54mm)
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.276" (7.00mm)
Contact Length - Post：0.118" (3.00mm)
Overall Contact Length：0.494" (12.54mm)
Insulation Height：0.100" (2.54mm)
Contact Shape：Square
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：-
Contact Finish - Post：Tin
Contact Material：Brass
Insulation Material：Polyamide (PA), Nylon, Glass Filled
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：150VDC

Headers, Male Pins datasheet and documents for 894-80-105-10-002101

894-80-105-10-002101

Headers, Male Pins Overview

The Preci-Dip 894-80-105-10-002101 is a vertical pin header connector from the 894 series, designed for board-to-board applications. It features 105 positions with a 0.100-inch (2.54mm) pitch and three rows. The connector utilizes square male pins made of brass with tin plating on both mating and post sections. Rated for 3A at 150VDC, it employs through-hole termination and push-pull locking. The housing is constructed from black glass-fiber-reinforced polyamide (PA), rated UL94 V-0, and operates within a temperature range of -55°C to 125°C.
