895-026-523-403

Edgeboard Connectors Overview

The EDAC Inc. 895-026-523-403 is a standard card edge connector from the 895 series, designed for single-edge applications. It features 26 positions with a 0.100-inch (2.54mm) pitch. The receptacle utilizes gold-plated contacts and solder pin termination for secure board attachment. Constructed with a black housing, this component supports a board thickness of 1.57mm and offers panel mount installation at a right angle.

Edgeboard Connectors Feature Summary

• Single-edge female connector configuration
• Gold-plated contact surfaces for reliable conductivity
• Solder pin termination method
• Right-angle panel mount design

Edgeboard Connectors Applications

• Industrial control systems
• Telecommunications equipment
• Medical devices
• Consumer electronics

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix to ensure correct contact plating and housing color specifications. Confirm that the target application requires a single-edge receptacle rather than a dual-edge variant. Check RoHS compliance documentation for environmental regulatory requirements. Ensure the mating card edge thickness aligns with the specified 1.57mm tolerance for proper mechanical engagement.

Edgeboard Connectors Selection Notes

Select this component when a single-edge connection is required for PCB integration. The 26-position count suits moderate density interconnect needs. The right-angle orientation facilitates compact panel mounting layouts. Gold plating ensures durability in environments requiring frequent insertion cycles or high reliability standards.

Edgeboard Connectors Part Context

This part belongs to the EDAC 895 series, which specializes in high-temperature card edge connectors. The series provides standardized solutions for board-to-board or board-to-backplane connections. The numbering convention indicates position count, pitch, and termination style within the manufacturer's catalog structure.

Edgeboard Connectors Replacement Considerations

Cross-reference with other 895-series variants for different position counts or plating options. Verify compatibility with mating card edges before substitution. Ensure mechanical dimensions match the existing enclosure constraints.
