895-031-544-608

Edgeboard Connectors Overview

The EDAC Inc. 895-031-544-608 is a single-row card edge connector designed for through-hole mounting. It features 31 female positions with a 0.100-inch (2.54mm) pitch. The contacts are made of copper alloy with gold plating, housed in a black polyphenylene sulfide (PPS) insulator. This component supports wire wrap termination and operates within a temperature range of -40°C to +125°C.

Edgeboard Connectors Feature Summary

• Single-edge female contact configuration for non-specified card types
• Gold-plated copper alloy contacts ensure reliable signal transmission
• Polyphenylene sulfide insulation provides thermal stability
• Wire wrap termination method facilitates secure PCB integration

Edgeboard Connectors Applications

• Industrial control system interconnects
• Telecommunications equipment backplanes
• Consumer electronics board-to-board connections
• Automotive electronic module interfaces

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to confirm exact pin count, plating thickness, and termination style. Ensure compatibility with the target card edge thickness and panel mounting requirements before procurement. Cross-reference the RoHS status and MSL rating with project specifications to guarantee regulatory compliance and storage handling procedures.

Edgeboard Connectors Selection Notes

Select this model when a single-row interface with 31 positions is required. The 0.100-inch pitch suits standard density applications. Verify that the wire wrap termination aligns with the assembly process. Confirm the PPS housing meets the environmental temperature expectations. Ensure the mechanical dimensions fit the designated panel cutout and mounting constraints.

Edgeboard Connectors Part Context

This component belongs to the EDAC 895 series of standard card edge connectors. The series offers various row counts and termination options. The 895-031 variant specifically addresses single-row needs. It complements other models in the lineup by providing a standardized interface solution for vertical or right-angle mounting configurations in electronic assemblies.

Edgeboard Connectors Replacement Considerations

Direct substitutes include other EDAC 895 series parts with matching 31-position single-row layouts. Verify identical pitch and termination methods. Alternative manufacturers may offer compatible generics if mechanical and electrical parameters align precisely with the original specification.
