Edgeboard Connectors Overview

The EDAC Inc. model 896-012-556-804 is a standard card edge connector receptacle designed for high-temperature applications. It features a dual female configuration with 12 positions and a contact spacing of 3.175 mm (0.125 inches). The component utilizes gold-plated copper alloy contacts and a polyphenylene sulfide (PPS) housing. It supports a nominal printed circuit board thickness of 1.57 mm and employs a solder pin termination method. The unit is rated for 3 A current and operates within a temperature range of -40 °C to +125 °C.

Edgeboard Connectors Feature Summary

• High-temperature resistant construction utilizing polyphenylene sulfide housing material
• Dual-edge female contact interface compatible with 0.125-inch pitch specifications
• Gold-plated copper alloy contacts ensuring reliable signal transmission

Edgeboard Connectors Applications

• Industrial control systems requiring robust thermal stability
• Automotive electronics modules
• Telecommunications infrastructure equipment
• Medical device internal connections

Edgeboard Connectors Procurement Notes

Verify the specific manufacturer part number against official EDAC documentation to confirm compatibility with system requirements. Ensure that the selected variant matches the required termination style and board thickness specifications. Cross-reference the datasheet for any recent product change notifications or environmental compliance updates prior to finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this component when a dual-edge card edge connector with a 3.175 mm pitch is required for panel mount installations. Confirm that the application environment remains within the specified operating temperature limits. Verify that the PCB design accommodates the 1.57 mm board thickness constraint and aligns with the solder pin termination process for secure mechanical attachment.

Edgeboard Connectors Part Context

This component belongs to the EDAC 896 series, which specializes in high-temperature card edge connectors. The series is engineered for demanding environments where standard connectors may fail due to thermal stress. The 896 series maintains consistent electrical performance across various position counts while adhering to strict dimensional tolerances for reliable mating cycles.

Edgeboard Connectors Replacement Considerations

Consult official EDAC substitution guides for verified alternative part numbers. Generic equivalents may not match the precise pitch, termination style, or thermal ratings required for this specific application.
